209-USP/UBP Gustav Stack
Upholstered Seat Pad | Upholstered Back Pad


32	21.5	19.5	INCH
81	55	50	CM

SKU: 209-USP/UBP Gustav Categories: Chairs, Gustav, Side, Stacking Chairs, Wood Chairs

Dimensions


32	21.5	19.5	INCH
81	55	50	CM

Upholstery

COM	0.75	Yards
COL	13.5	Sq. Ft.

Comments

Comes standard in stack version.

Stacks: 5

Specifications

• Chair frame shall be constructed from solid kiln dried beech. Lumber to be dried to a final moisture content between 6% – 8%.
• Front and rear legs to be constructed from single stock lumber. Finished dimension at the top of leg to be 1 ½” x 1 ¼” tapering to 1” x 1” at bottom.
• Front and rear legs are attached by an X stretcher made of solid beech frame that is ¾” x 1”.
• The chair frame and seat frame are connected together by dowels, corner blocks, bolts and glue.
• The seat is built of ½” thick solid core ply applied to the solid beech frame. The seat is attached to the beech frame via screws. High density CAL 117 FR foam and upholstery are applied after assembly – if applicable.
• Back is 1” thick beech wood steam bent that is glued & doweled to the back upright backs can be upholstered inside only.

Print Specifications
