195-SB Utopia Arm
Sled Base


30.5	22	24	24	INCH
79	56	61	61	CM

SKU: 195-SB Utopia Arm Categories: Arm, Chairs, Guest Chairs, Metal Chairs, Utopia

Dimensions


30.5	22	24	24	INCH
77	56	61	61	CM

Upholstery

COM	2	Yards
COL	36	Sq. Ft.

Comments

This item requires textile approval prior to production. Click here to see a wide range of pre-approved textiles.

Textiles that have not been reviewed will require a memo sample. Memo samples can be ordered and sent to ISA directly from the manufacturer’s website. An Upholstery Approval Form must be filled out and submitted to ISA along with memo sample.

Standard with double stitching upholstery. Zig zag stitch is special order. See #1195 for matching stool.

Specifications

• Chair starts with a cold molded foam shell, which is made from a metal frame injected with PU foam.
• Shell seat is then wrapped in ¼” high density CAL 117 FR foam.
• Shell back and sides is wrapped in Dacron.
• Available in the following bases:
Straight Metal Leg (SMLG) version is manufactured using Ø16 mm steel tubing. Available in any standard ISA powder coat or plated finish.
Tapered Metal Legs (TMLG) version is manufactured using Ø38 mm, 16 gauge steel tube. Leg is Ø38 mm at the top and tapers down to Ø16 mm. Available in any standard ISA powder coat or plated finish.
Tapered Wood Legs (TWLG) are tapered and made from Ash wood. Leg is Ø40 mm at the top tapering down to Ø25 mm. Available in any standard ISA wood finish.
Sled Base (SB) version is manufactured using Ø11 mm steel rod in polished chrome finish.
Adjustable Desk Base (ADKB) Five prong metal base (26” x 26” spread) with dual wheel casters, swivel, locking and tension control tilt & gas lift mechanism. Finished in Polished Aluminum/P77. Seat height ranges from 21.5” to 28.5” (counter and bar)
Beech Plywood Legs (PLGB) High frequency molded with 30 layers, 1 1/8” thick. Legs taper from 2” at the top to 1 ¼” at the bottom. Profile is machined for an aesthetic V-shape. Available in any ISA standard wood finish.
Walnut Plywood Legs (PLGW) High frequency molded, with 30 layers, 1 1/8” thick. Legs taper from 2” at the top to 1 ¼” at the bottom. Profile is machined for an aesthetic V-shape. Finished with clear coat.
Desk Base (DKB) Five prong metal base (26” x 26” spread) with dual wheel casters, swivel, locking and tension control tilt & gas lift mechanism. Finished in Polished Aluminum/P77. Seat height ranges from 18.5 to 22.5 (desk)
Quatre Wood Base (QTW) Solid Ash 4-prong base with no-return swivel. Tapers from 4 ½” x 1 ½” at the top to 1 ½” x 1” at the bottom. Finished in any standard ISA wood finish.

Print Specifications

Finishes

PLATED METAL FINISHES

 P77 Polished Chrome 

Pre-Approved Textiles

The listing below provides a wide range of textiles that have been approved for use on most ISA seating products.
Click here for a list of products that require textile approval.

Some exclusions may apply and will be noted. Textiles that have not been reviewed will require a memo sample to be submitted to ISA for testing. Please fill out our Upholstery Approval Form and submit to ISA in order to track your memo and provide a written correspondence following review. ISA welcomes customers to provide COM or alternatively we are pleased to quote any upholstery material upon request.
